Product Description
eMMC BGA100 128GB is a high-capacity consumer embedded storage solution designed for smart devices, consumer electronics, and embedded applications requiring reliable and efficient data storage. Integrating high-quality NAND Flash memory with an advanced eMMC controller, it delivers stable performance, low power consumption, and simplified system integration for mass-production electronic devices.
Featuring a compact BGA100 package, the eMMC BGA100 128GB provides a space-saving storage solution with excellent compatibility for modern embedded platforms. Its integrated storage management functions help improve reliability and optimize data handling in various consumer applications.
The eMMC BGA100 128GB is ideal for smart TVs, tablets, smart projectors, AI terminals, smart displays, set-top boxes, and other intelligent devices requiring high-density embedded storage.
key features
Compact Package
Designed with a standard BGA100 package, YOTTAWIN eMMC provides a compact and flexible storage solution for space-constrained embedded designs.
128GB Embedded Capacity
We do multiple tests before leaving the factory. And we have passed ISO 9001, CE and other quality tests.
Stable Performance
YOTTAWIN eMMC delivers stable performance, low power consumption, and reliable operation under standard operating environments.
Techonical support
YOTTAWIN eMMC solutions combine NAND Flash and an integrated controller in one package, providing easy system integration and reliable storage management.
Product Specification
|
Capacity |
Continuous write (MB/s) |
Continuous read (MB/s) |
Random write (IOPS) |
Random read (IOPS) |
|
8GB |
Up to 120 |
Up to 220 |
Up to 2800 |
Up to 3100 |
|
16GB |
Up to 120 |
Up to 240 |
Up to 2800 |
Up to 3200 |
|
32GB |
Up to 120 |
Up to 260 |
Up to 3000 |
Up to 3300 |
|
64GB |
Up to 200 |
Up to 260 |
Up to 3000 |
Up to 3600 |
|
128GB |
Up to 200 |
Up to 260 |
Up to 3100 |
Up to 3700 |
|
256GB |
Up to 210 |
Up to 260 |
Up to 3200 |
Up to 3800 |
Supported Functions
HS400,HS200,DDR52,SDR52
High Priority Interrupt (HPI)
Back-end operation, BKOPS control
Packed CMD, command queue
Cache,Cache Flushing Report,Cache Barrier(Optional)
Partition, partition type, RPMB, RPMB bandwidth optimization
Discard,Trim,Erase,Sanitize
Write protection, secure write protection (optional)
Lock/unlock
Power off power notification (PON), Sleep/Awake
Enhance reliability write operations
Boot feature,Boot partition
Hardware/software reset
Configurable drive capability
Compatible Platforms
|
AP vendor |
AP model P/N |
|
RockChip |
RK3126 |
|
RK3228, RK3228H, RK3229, RK328X |
|
|
RK3308, RK3318, RK3328, RK3326, RK3368, RK3368H, RK3399 |
|
|
RK3566, RK3568, RK3588,RK3506 |
|
|
RK1808 |
|
|
RKPX30 |
|
|
RV1126, RV1109, RV1108, V1107 |
|
|
MTK |
MT8163, MT8167, MT8168, MT8173 |
|
MT8735, MT8735B, MT8735M, MT8765, MT8766, MT8783, MT8788 |
|
|
MT8937 |
|
|
MT6580 |
|
|
MT6735, MT6737, MT6739, MT6753, MT6761, MT6763 |
|
|
Amlogic |
S805 |
|
S905X, S905X2, S905X3, S905W |
|
|
Allwinner |
A20, A33, H6,T3,T536 |
|
Intel |
Cherry Trail |
|
Apollo Lake |
|
|
Celeron N4000 |
|
|
Spreadtrum |
SC7731E, SC9832, SC9863 |
|
Qualcomm |
S801 |
|
Others |
Actions, VIA, InfoTMIC, Realtek, Nvidia, Hisilicon, Msta |
Product application
Why Choose YOTTAWIN
Backed by nearly two decades of experience in embedded storage development, YOTTAWIN delivers reliable eMMC storage solutions for consumer, industrial, and embedded applications. By integrating proprietary controller technology, advanced Flash FTL algorithms, and high-quality 3D NAND Flash, our eMMC products achieve stable performance, enhanced durability, strong compatibility, and reliable long-term availability.
Through continuous innovation in storage architecture, firmware optimization, and quality management, YOTTAWIN provides customized and dependable embedded storage solutions that meet the requirements of smart devices, IoT applications, industrial equipment, and other systems demanding high reliability and extended product support.
Flexible MOQ
High Reliability
Self-Developed Controller
Strong Compatibility
Quality & Reliability
Our eMMC products undergo comprehensive validation and reliability testing to ensure stable performance in demanding embedded applications.
Reliability Testing
High & Low Temperature Test
Read/Write Endurance Test
Power Cycle Test
Data Retention Test
Vibration Test
Mechanical Shock Test
Thermal Cycling Test
Compatibility Verification
Burn-in Test
Power Failure Protection Verification
Quality Certifications
RoHS
ISO
FC
CE
Ordering & Logistics
YOTTAWIN offers reliable ordering and logistics services for eMMC BGA 100 128GB, including secure ESD packaging, flexible MOQ, fast sample delivery, OEM/ODM support, and worldwide shipping. With stable supply and efficient global logistics, we help customers shorten development cycles and support high-volume production.
Product Models
|
Part Number |
Density |
Package size |
Package Type |
|
DYE008GFTC-EX |
8GB |
11.50×13.00×1.00(mm) |
PBGA-153-Ball |
|
DYE016GFTC-EX |
128GB |
11.50×13.00×1.00(mm) |
PBGA-153-Ball |
|
DYE032GFTC-EX |
128GB |
11.50×13.00×1.00(mm) |
PBGA-153-Ball |
|
DYE064GFTC-EX |
64GB |
11.50×13.00×1.00(mm) |
PBGA-153-Ball |
|
DYE128GFTC-EX |
128GB |
11.50×13.00×1.20(mm) |
PBGA-153-Ball |
|
DYE256GFTC-EX |
128GB |
11.50×13.00×1.20(mm) |
PBGA-153-Ball |
|
DYE008GOHC-EX |
8GB |
14.00×18.00×1.40(mm) |
PBGA-100-Ball |
|
DYE016GOHC-EX |
128GB |
14.00×18.00×1.40(mm) |
PBGA-100-Ball |
|
DYE032GOHC-EX |
128GB |
14.00×18.00×1.40(mm) |
PBGA-100-Ball |
|
DYE064GOHC-EX |
64GB |
14.00×18.00×1.40(mm) |
PBGA-100-Ball |
|
DYE128GOHC-EX |
128GB |
14.00×18.00×1.40(mm) |
PBGA-100-Ball |
|
DYE256GOHC-EX |
128GB |
14.00×18.00×1.40(mm) |
PBGA-100-Ball |
FAQ
Q: What is eMMC BGA 100 128GB?
A: eMMC BGA 100 128GB is an embedded storage solution that integrates NAND Flash memory and an eMMC controller into a single BGA 100 package. It provides a compact, cost-effective, and easy-to-integrate storage solution for consumer electronics and embedded devices.
Q: What is the difference between BGA 153 and BGA100?
A: The main differences are package size, pin count, and application compatibility. eMMC BGA 153 128GB provides more signal pins and is widely used in industrial automation, medical devices, communication equipment, and other embedded systems. BGA100 is more commonly used in compact consumer electronics with limited PCB space.
Q: What is the difference between Commercial eMMC and Industrial eMMC?
A: eMMC supports an operating temperature range of -40°C to +85°C, offering enhanced endurance, improved data integrity, and a longer product lifecycle. Commercial eMMC typically operates from 0°C to +70°C and is intended for standard consumer electronics.
Q: What is the MOQ?
A: The standard MOQ for eMMC BGA 100 128GB is 100 pieces. For volume orders or OEM/ODM projects, please contact our sales team for customized pricing and delivery schedules.
Q: Are samples available?
A: Yes. We provide sample support for eMMC BGA 100 128GB to help customers evaluate product performance and verify compatibility before mass production. Please contact our sales team for sample availability and delivery details.
Q: Which platforms are supported?
A: YOTTAWIN eMMC BGA 100 128GB is compatible with mainstream embedded platforms, including NXP i.MX, Rockchip, Allwinner, Amlogic, MediaTek, TI Sitara, and Renesas processors that support the eMMC 5.1 specification.
