Products Description
Our RF LNA series represents a portfolio of high-performance RF front-end components engineered for critical signal reception in demanding applications. Leveraging advanced GaAs HEMT technology and precision matching networks, these amplifiers deliver ultra-low noise figures, stable gain, and exceptional linearity across multiple frequency bands-from L-band (1-2GHz) to Q-band (33-50GHz) and broadband solutions (1-18GHz, 18-40GHz) .
Designed for both indoor integration and outdoor harsh environments, our LNAs feature rugged enclosures, wide operating temperature ranges, and optimized power efficiency. Each unit undergoes rigorous testing to ensure compliance with global aerospace and telecommunications standards, making them the preferred choice for satellite communication, radar, GNSS, and wireless infrastructure projects worldwide.
Products Specification
|
Frequency Band Series |
Noise Figure (NF) |
Gain |
1dB Compression Point (P1dB) |
IP3 (Third-Order Intercept Point) |
Operating Frequency Range |
VSWR |
|
C-Band LNA |
≤0.6dB |
20-25dB |
≥-15dBm |
≥+25dBm |
4-8GHz |
<1.5:1 |
|
Ku-Band LNA |
≤0.8dB |
18-22dB |
≥-12dBm |
≥+28dBm |
12-18GHz |
<1.5:1 |
|
Ka-Band LNA |
≤1.0dB |
15-20dB |
≥-10dBm |
≥+30dBm |
26.5-40GHz |
<1.8:1 |
|
L-Band LNA |
≤0.5dB |
22-28dB |
≥-18dBm |
≥+22dBm |
1-2GHz |
<1.4:1 |
|
S-Band LNA |
≤0.7dB |
20-25dB |
≥-16dBm |
≥+24dBm |
2-4GHz |
<1.5:1 |
|
X-Band LNA Group |
≤0.6dB |
25-30dB |
≥-14dBm |
≥+26dBm |
8-12GHz |
<1.5:1 |
|
P-Band LNA |
≤0.9dB |
18-23dB |
≥-17dBm |
≥+23dBm |
200-1000MHz |
<1.6:1 |
|
Q-Band LNA |
≤1.2dB |
14-18dB |
≥-8dBm |
≥+32dBm |
33-50GHz |
<2.0:1 |
|
1-18GHz Broadband LNA |
≤1.5dB (typ) |
16-20dB |
≥-13dBm |
≥+27dBm |
1-18GHz |
<1.8:1 |
|
18-40GHz Broadband LNA |
≤1.8dB (typ) |
12-16dB |
≥-9dBm |
≥+29dBm |
18-40GHz |
<2.0:1 |
Products Features
Ultra-Low Noise Performance: Adopts GaAs HEMT technology to achieve noise figures as low as 0.5dB (L-band), minimizing signal degradation in weak-signal scenarios such as deep-space communication . The optimized input matching network ensures NF stability across the entire operating band.
High Linearity & Dynamic Range: Boasts excellent IP3 (+22~32dBm) and P1dB (-8~-18dBm) to suppress intermodulation distortion caused by strong interference signals, ideal for crowded frequency environments like 5G base stations and satellite earth stations .
Harsh Environment Durability: Features IP67 waterproof aluminum enclosures, vibration/shock resistance, and wide temperature operation (-40~+60℃), suitable for outdoor satellite terminals, marine radar, and polar expedition equipment .
Redundancy-Ready Design: Supports 1+1 and 1+2 redundant configurations with automatic switchover (≤5ms), minimizing downtime for mission-critical systems such as military radar and commercial geosynchronous satellite links .
Integrated Filtering Option: Available with bandpass pre-filtering to provide >60dB out-of-band rejection, preventing adjacent-channel interference without sacrificing noise performance .
Advantages
Solid Operational Stability
Strong financial foundation ensures long-term reliability; standardized governance reduces risks.
Advanced R&D & Production Capabilities
SO 14644 Class 100,000 cleanroom (micro-packaging),meets strict aerospace manufacturing standards.
100+ test instruments (0.1–67GHz) enable full-process quality control for precision products.
300+ professional team (R&D, production, integration) guarantees efficient project delivery.
Leading Position in Aerospace Sector
Specializes in aerospace ground equipment (R&D, production, integration); products applied in:
satellite communication, remote sensing, TT&C, radio monitoring, spectrum awareness.
Supports over 80% of satellite ground station projects within its key market; supplies critical equipment for major aerospace initiatives (manned spaceflight, lunar exploration, etc.).
Powerful Technological Innovation
Leading RF integrated design supplier in its industry sector; original inventor & patent holder of large-scale matrix switching technology.
Products Application
Service
Customization Support
Tailor frequency range, gain, packaging (SMT/connectorized), and filtering options to meet specific system requirements.
Warranty & Maintenance
3-year global warranty with free repair /replacement. 24/7 technical support via email/phone, with on-site troubleshooting for bulk orders.
FAQ
Q: What is the difference between narrowband and broadband LNAs in your series?
A: Narrowband LNAs (e.g., C/Ku-band) are optimized for specific frequencies with lower NF (<1dB) and higher gain, while broadband models (1-18GHz) offer flexible multi-band coverage for SDR and 5G applications, with slightly higher typical NF (1.5dB) .
Q: Can your LNAs operate with unregulated power supplies?
A: Yes, all models include built-in voltage regulation (5-15V DC) and reverse-polarity protection. However, we recommend regulated supplies for optimal NF stability (<±0.1dB variation) .
Q: How does GaAs HEMT technology improve performance compared to silicon-based LNAs?
A: GaAs HEMTs have 5-8x higher electron mobility, enabling lower noise (NF reduced by 30-50%) and higher operating frequencies (up to 50GHz vs. 10GHz for silicon) - critical for satellite and radar applications .
Q: Do you offer redundant systems for mission-critical applications?
A: Yes, we provide 1+1 and 1+2 redundant LNA systems with automatic switchover (<5ms). These include a controller module, primary/backup units, and status monitoring via RS485 .
Q: What is the maximum cable length between the antenna and LNA?
A: For optimal performance, we recommend ≤10m for L-band (low loss) and ≤5m for Ka/Q-band (high-frequency loss). We can provide custom low-loss cables as part of the solution .
Q: How do I select the right LNA based on my system's noise budget?
A: Use Friis formula: Total NF ≈ LNA NF + (Subsequent NF - 1)/LNA Gain. Our engineers can calculate the required NF/gain for your system-contact us with your receiver's noise figure and cable loss .
Q: Can you modify the LNA for radiation-hardened applications (space use)?
A: Yes, our space-grade option uses radiation-hardened GaAs HEMTs and ceramic packaging, meeting MIL-STD-883G for total ionizing dose (TID) >100krad .
Q: Are your LNAs compatible with outdoor antenna mounts?
A: Yes, all models have IP67-rated enclosures and mounting flanges (NEMA standard), suitable for direct antenna integration. We also offer pole-mount kits for VSAT terminals .
